Stainless Steel Condensate Pot

Name: Stainless Steel Condensate Pot
Brand: DELIXIN ENTERPRISES
Price: 8000.0 INR
Availability: InStock

Price 8000.0 INR/ Piece

Get a Price/Quote

MOQ : 50 Pieces

Stainless Steel Condensate Pot Specification

Features
Corrosion Resistant, Rugged Construction, Easy Installation & Maintenance

Material
Stainless Steel 304/316/316L

Control System
Manual (Passive Device)

Connection Type
Threaded or Flanged Ends

Structure
Cylindrical Vessel with welded flanged or threaded connections

Application
Used in steam and condensate lines to collect and drain condensate, prevents direct contact of hot steam with instruments

Sealing
Welded, Leak-proof

Type
Condensate Pot

Pressure
Up to 6000 PSI (as per model selection)

Media
Steam, Condensate, Fluids

Port Size
1/2 to 2 (customized as per requirement)

Temperature
Suitable for temperatures up to 400C

Drain Outlet
Provided for Complete Draining

Inlet/Outlet Connections
BSP/NPT Threads or Flanged Ends

Insulation Option
Available on Request

Mounting
Horizontal or Vertical Installation

Weight
Depends on Size and Material

Standards
ASME, DIN, ISO (as per request)

Capacity
Available from 500 ml to 3 liters (or as customized)

Finish
Polished, Pickled or Sandblasted

End Connections
Socket Weld, Butt Weld, or Screwed

Testing
100% Hydro-tested before Dispatch

Stainless Steel Condensate Pot About

Condensate Pot Design requires the unit to be held at the same level as that of pipe. This minimizes the possible error that might arise due to the unequal level of the fluid.

Condensate Pot For Pressure Transmitters require the heat to be traced and impulse lines to be insulated. Antifreeze media such as glycol may be added to the water lines. Condensate Pot Parker is ideally designed to trap any foreign material and prevent the pipeline from getting damaged. Steam Condensate Pot Working Principle recommends that the impulse line from the condenser pot to the DP should have the facility for blowdown. Parker Condensate Pot is supplied by us to various industries. Condensate Pot Swagelok are manufactured as per international standards and are passed through various tests to confirm their properties.

BRAND NAME	DELIXIN-LOK
PIPE SIZE	2" NB TO 8" NB
SCHEDULE	SCH 40, SCH 80, SCH 160, SCH XXS
LENGTH	8" TO 16" OR LARGER
CONNECTION	THREADED, SOCKET WELD END
THREADS	NPT, BSPP, BSPT
NO. OF PORTS	2 PORT, 3 PORT, 4 PORT & MORE AS PER DRAWING
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
BODY TYPE	SEAMLESS PIPE
MATERIAL	SS 316, SS 304, BRASS, SS 316 TI, CS, COPPER, SUPER DUPLEX, INCONEL, DUPLEX, HASTELLOY, MONEL, ALLOY 20, SMO 254, 904L , TITANIUM & ALL OTHER ALLOYS

Versatile Mounting and Installation

Our condensate pots are designed for both horizontal and vertical installations to suit different pipeline configurations. Equipped with inlet/outlet options such as BSP/NPT threads or flanged ends, and drain outlets for complete draining, they offer user-friendly and flexible integration into steam and fluid handling systems.

Rugged Performance in Demanding Environments

Constructed from corrosion-resistant stainless steel (304/316/316L), these pots are built for durability, thermal endurance up to 400C, and operation under pressures up to 6000 PSI. Each vessel is 100% hydro-tested before dispatch to guarantee leak-proof performance, making them ideal for industrial applications.

Customizable to Application Needs

Available in capacities from 500 ml to 3 liters-or fully customized dimensions-these condensate pots accommodate a wide spectrum of steam, condensate, and fluid handling needs across industries. Optional insulation and a variety of end connections ensure adaptability for specific operational requirements.

FAQ's of Stainless Steel Condensate Pot:

Q: How is a stainless steel condensate pot used in a steam line?

A: A stainless steel condensate pot collects and temporarily holds condensate from steam lines, preventing direct exposure of downstream instrumentation to hot steam, and enabling safe drainage through a dedicated outlet.

Q: What is the recommended process for installing the condensate pot?

A: For installation, select horizontal or vertical mounting as suitable for your pipeline. Secure with the appropriate end connections-threaded, flanged, or welded-ensuring the inlet/outlet and drain align with your system layout, and perform all work according to standards such as ASME, DIN, or ISO.

Q: When should I use insulation with the condensate pot?

A: Insulation is recommended when operating at high temperatures or in environments where heat loss, condensation outside the vessel, or personnel protection is a concern. Insulation is available on request and should be specified during ordering.

Q: Where can the condensate pot be mounted in the system?

A: The condensate pot is typically installed on steam or condensate lines upstream of sensitive instrumentation such as pressure transmitters or flow meters, wherever condensate collection and protection from steam is required.

Q: What are the benefits of using stainless steel 304/316/316L material for the condensate pot?

A: Stainless steel 304/316/316L offers excellent corrosion resistance, durability under high pressure and temperature, and ensures longevity and low maintenance in demanding steam and fluid applications.

Q: How is the condensate pot tested before dispatch?

A: Each unit undergoes 100% hydro-testing to verify there are no leaks and to ensure integrity under the pressure specified (up to 6000 PSI, depending on the model selected).

Q: What customization options are available for the condensate pot?

A: Customization is offered in terms of vessel capacity (500 ml to 3 liters or as needed), finish (polished, pickled, or sandblasted), mounting orientation, insulation, end connection types (BSP/NPT, flanged, welded), and port sizes.
