Instruments Air Header

Name: Instruments Air Header
Brand: DELIXIN ENTERPRISES
Price: 12000.0 INR
Availability: InStock

Price 12000.0 INR/ Piece

Get a Price/Quote

MOQ : 25 Pieces

Instruments Air Header Specification

Connection Type
Threaded (NPT/BSPT) or Flanged Ends

Material
Stainless Steel 304/316, Carbon Steel

Valve Size
1/4 to 1 (ball valve branches)

Features
Multiple branch outlets, corrosion resistant, leak proof design, easy installation

Valve Type
Ball Valve Outlets

Control System
Manual Lever Operation

Structure
Cylindrical header with multiple branch outlets, mounted on fixed support legs

Application
Distribution of instrument air to various pneumatic devices and instruments

Sealing
PTFE / Graphite Gasket

Type
Air Header Manifold

Pressure
Up to 6000 PSI

Media
Compressed Air, Gases

Port Size
1/2 to 2 (customizable)

Temperature
-20C to 200C

Finish
Electropolished / Pickled / Passivated

Standards
ASME, ANSI, DIN (on request)

Color (Handle)
Red

Mounting
Skid/foot mounted

No. of Outlets
4 to 20 (standard/custom as required)

Test
Hydro and pneumatic tested as per standards

Inlet Size
1" to 2" Flange/Threaded

Accessories
End plugs, vent/drain valves (optional)

About Instruments Air Header

Specification of Instrument Air Header Air Header is a series of multiple valve assemblies that operate from one originating point. air header manufacturers in India designed these valves in a way that they can accommodate various valves. The inlet connection of the valve has multiple outlet connections. The instrument air header has a lockable handle that prevents unwanted manual actuation of the outlet valve. Moreover, these air header manifolds also reduce the assembly time. The instrument air distribution manifold has multiple chambers with multiple branches of outlets that deliver air to several consumers.

BRAND NAME	DELIXIN-LOK
BODY SIZE	1" NB TO 4" NB
SCHEDULE	SCH 40, SCH 80, SCH 160, SCH XXS
LENGTH	8" OR LARGER
NO. OF OUTLET PORTS	2 WAYS TO 20 WAYS
VALVE TYPE	BALL VALVE & NEEDLE VALVE
VALVE END CONNECTION	FEMALE THREADED, MALE THREADED, TUBE END
CONNECTION SIZE	UPTO 1/2"
INLET & OUTLET CONNECTION	BALL VALVE, NEEDLE VALVE, FLANGED
WORKING PRESSURE	UPTO 10,000 PSI
THREADS	NPT, BSPP, BSPT
SEALS	PTFE, GRAPHITE, PEEK
BODY TYPE	SEAMLESS PIPE, BAR STOCK
OPTIONS	MOUNTING BRACKET
MATERIAL	SS 316, SS 304, SS 316 TI, COPPER, BRASS, DUPLEX, CS, INCONEL, SUPER DUPLEX, HASTELLOY, MONEL, ALLOY 20, SMO 254, 904L, TITANIUM & ALL OTHER ALLOYS

Versatile Design and Customization

Our air headers are engineered to accommodate 4 to 20 outlets, with options for customizations based on your system requirements. From port sizes and inlet connections to mounting style, material, and surface finish, every aspect can be tailored for optimal integration and performance in your facility.

Superior Quality and Safety

All headers are manufactured using high-grade stainless steel (304/316) or carbon steel, and each unit is electropolished, pickled, or passivated for enhanced corrosion resistance. Strict adherence to ASME, ANSI, and optional DIN standards, along with comprehensive hydro and pneumatic testing, guarantees both safety and long-term reliability.

Effortless Operation and Maintenance

With manual lever control and leak-proof PTFE or graphite gasket sealing, users benefit from straightforward operation and minimal maintenance. Accessories like end plugs and vent/drain valves can be included for added convenience, while the modular design simplifies both installation and future expansion.

FAQ's of Instruments Air Header:

Q: How do I choose the correct number of outlets for my instrument air header?

A: Select the number of outlets based on the total number of instruments or pneumatic devices that require air supply in your application. We offer standard headers with 4 to 20 outlets and can customize further to match your operational requirements.

Q: What are the main advantages of using a stainless steel air header manifold?

A: Stainless steel air headers (304 or 316) provide superior corrosion resistance, durability, and leak-proof performance, even in demanding temperature (20C to 200C) and pressure (up to 6000 PSI) environments. Their robust design ensures long service life and optimal protection for connected instruments.

Q: When should I consider custom configurations instead of standard air headers?

A: Opt for custom configurations if your system needs unique port sizes, non-standard inlet/outlet arrangements, specialized mounting, or specific international standards such as DIN. Customization ensures the manifold integrates seamlessly with your process equipment.

Q: Where are these air headers typically installed?

A: Air headers are commonly installed in industrial plants, process control rooms, refineries, and automation systems. They are mounted on skids or fixed foot supports to provide centralized distribution of instrument air to valves, gauges, and other pneumatic instruments.

Q: What testing processes are performed to ensure product reliability?

A: Each air header undergoes hydro and pneumatic testing as per ASME or ANSI standards to ensure leak-tightness, pressure sustainability, and overall reliability. On request, we can also conduct testing to DIN specifications.

Q: How do the optional accessories improve usage?

A: Accessories such as end plugs and vent/drain valves facilitate maintenance, safe operation, and faster draining or venting, thus improving usability and extending the lifespan of the header and downstream devices.

Q: What installation and maintenance benefits does the design provide?

A: The header's cylindrical structure, easy mounting, and modular valve installation enable quick setup. The leak-proof design and corrosion-resistant finish minimize maintenance needs and reduce operational downtime.
