SS 304 Tube Clamps

Name: SS 304 Tube Clamps
Brand: DELIXIN ENTERPRISES
Price: 250.0 INR
Availability: InStock

Price 250.0 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

SS 304 Tube Clamps Specification

Product Type
Tube Clamp

Material
Stainless Steel 304 (SS 304)

Type
Hydraulic Pipe / Tube Clamp

Shape
Round (for the tube opening), Rectangular (overall body)

Technique
Injection Molding & Machining

Surface Treatment
Polished / Zinc-Plated / Shot Blasted (depending on component)

Standard
DIN 3015

Outer Diameter
Matches pipe O.D. (6mm to 101.6mm)

Length
Standard as per DIN 3015 (varies by size)

Inside Diameter
Customizable as per tube size requirement (typically 6mm to 101.6mm)

Wall Thickness
Standard as per design specifications (varies with tube size)

Tensile Strength
550 MPa Minimum (for SS 304 metal components)

Grade
SS 304

Size
Diverse Range: Available for 6mm to 101.6mm tubing

Color
Green (Clamp Body)

Installation
Easy to assemble and disassemble, modular design

Metal Plate Material
Stainless Steel 304 (Standard), also available in SS316, Carbon Steel

Temperature Resistance
-30C to +90C (PP body), Up to +120C for PA, higher for Aluminium

Customization
Available for different tube sizes, special mounting requirements

Corrosion Resistance
Excellent due to SS 304 and plastic body

Noise / Vibration Control
Yes, ribbed design minimizes vibration and noise

Fire Resistance
PA and Aluminum models are fire-resistant

Clamp Body Material
Polypropylene, Polyamide, Aluminum (as per design/request)

Mounting Type
Welded Base / Rail Mounted / Single & Double Clamp

Application
Hydraulic Pipes, Process Tubes, Pneumatic Lines, Instrumentation Lines

Bolt/Nut Material
Stainless Steel 304

About SS 304 Tube Clamps

Brand	DELIXIN-LOK
Equivalent To	STAUFF, SWAGELOK, PARKER
Structure	SS 304 tube clamp
Material	Jaws Polypropylene, Aluminum, Polyamide Top & Bottom Plate and Bolt Steel or Stainless Steel
Size Range	OD 6 mm 76.1 MM
Color	Silver

Top Bottom Plates

Steel (ST 37.5, IS 2062, IS 1018) With Trivalent Zinc Coated/phosphatised Finish.
Stainless Steel ( SS 304) With Natural Finish
Bolts Steel ( 4.6, 8.8, 10.9 Grade), Stainless Steel (SS 304, SS 316 Grade)
Size 6 Mm To 219mm To 8
Series - Standard Series Heavy Series

Grade	(% in 50mm) Elongation minimum	0.2% Proof Yield Strength (MPa) minimum	Strength of Tensile (MPa) minimum	Plate Hardness
Brinell (HB) max	Rockwell B (HR B) max
304	40	205	515	201	92
304L	40	170	485	201	92
304H	40	205	515	201	92

Grade	Mn	C	Si	S	Cr	P	N	Mo
304	minimum maximum	- 2.0	- 0.08	- 0.75	- 0.030	18.0 20.0	- 0.045	- 0.10	-
304L	minimum maximum	- 2.0	- 0.030	- 0.75	- 0.030	18.0 20.0	- 0.045	- 0.10	-
304H	minimum maximum	- 2.0	0.04 0.10	- 0.75	- 0.030	18.0 20.0	-0.045	-	-

Grade	British	Euronorm	UNS No.	SS	JIS
European Standards	British Standards	Name	DIN No.
304	58E	304S31	X5CrNi18-10	1.4301	S30400	2332	SUS 304
304L	-	304S11	X2CrNi19-11	1.4306	S30403	2352	SUS 304L
304H	-	304S51	X6CrNi18-11	1.4948	S30409	-	-

Suitable for general hydraulic applications.

All dimensions are in millimetres (mm).

Group	DELIXIN-LOK Part Code	Pipe OD	a2	a3	a1	b1	G	S	h1	h3	Hex Bolt
1	DELIXIN-LOK PCL 6 MM	6	43	34	20	30	0.4	3	27	33	M6 30 mm
1	DELIXIN-LOK PCL 6.4 MM (1/4)	6.4	43	34	20	30	0.4	3	27	33	M6 30 mm
1	DELIXIN-LOK PCL 8 MM	8	43	34	20	30	0.4	3	27	33	M6 30 mm
1	DELIXIN-LOK PCL 9.5 MM (3/8)	9.5	43	34	20	30	0.4	3	27	33	M6 30 mm
1	DELIXIN-LOK PCL 10 MM	10	43	34	20	30	0.4	3	27	33	M6 30 mm
1	DELIXIN-LOK PCL 12 MM	12	43	34	20	30	0.4	3	27	33	M6 30 mm
2	DELIXIN-LOK PCL 12.7 MM (1/2)	12.7	48	42	26	30	0.6	3	3233	38	M6 37 mm
2	DELIXIN-LOK PCL 13.7 MM	13.7	48	42	26	30	0.6	3	3233	38	M6 37 mm
2	DELIXIN-LOK PCL 14 MM (9/16)	14	48	42	26	30	0.6	3	3233	38	M6 37 mm
2	DELIXIN-LOK PCL 15 MM	15	48	42	26	30	0.6	3	3233	38	M6 37 mm
2	DELIXIN-LOK PCL 16 MM (5/8)	16	48	42	26	30	0.6	3	3233	38	M6 37 mm
2	DELIXIN-LOK PCL 17.2 MM	17.2	48	42	26	30	0.6	3	3233	38	M6 37 mm
2	DELIXIN-LOK PCL 18 MM	18	48	42	26	30	0.6	3	3233	38	M6 37 mm
3	DELIXIN-LOK PCL 19.05 MM (3/4)	19.05	56	50	33	30	0.6	3	36	42	M6 40 mm
3	DELIXIN-LOK PCL 20 MM	20	56	50	33	30	0.6	3	36	42	M6 40 mm
3	DELIXIN-LOK PCL 21.3 MM	21.3	56	50	33	30	0.6	3	36	42	M6 40 mm
3	DELIXIN-LOK PCL 22 MM	22	56	50	33	30	0.6	3	36	42	M6 40 mm
3	DELIXIN-LOK PCL 25.4 MM (1)	25.4	56	50	33	30	0.6	3	36	42	M6 40 mm
4	DELIXIN-LOK PCL 26.9 MM	26.9	62	60	40	30	0.6	3	42	48	M6 45 mm
4	DELIXIN-LOK PCL 28 MM	28	62	60	40	30	0.6	3	42	48	M6 45 mm
4	DELIXIN-LOK PCL 30 MM	30	62	60	40	30	0.6	3	42	48	M6 45 mm
5	DELIXIN-LOK PCL 32 MM (1-1/4)	32	74	70	52	30	0.8	3	58	64	M6 60 mm
5	DELIXIN-LOK PCL 33.7 MM	33.7	74	70	52	30	0.8	3	58	64	M6 60 mm
5	DELIXIN-LOK PCL 35 MM	35	74	70	52	30	0.8	3	58	64	M6 60 mm
5	DELIXIN-LOK PCL 38 MM (1-1/2)	38	74	70	52	30	0.8	3	58	64	M6 60 mm
5	DELIXIN-LOK PCL 40 MM	40	74	70	52	30	0.8	3	58	64	M6 60 mm
5	DELIXIN-LOK PCL 42 MM	42	74	70	52	30	0.8	3	58	64	M6 60 mm
6	DELIXIN-LOK PCL 44.5 MM	44.5	88	86	66	30	0.8	3	66	72	M6 70 mm
6	DELIXIN-LOK PCL 48.3 MM	48.3	88	86	66	30	0.8	3	66	72	M6 70 mm
6	DELIXIN-LOK PCL 50.8 MM (2)	50.8	88	86	66	30	0.8	3	66	72	M6 70 mm
6	DELIXIN-LOK PCL 53 MM	53	88	86	66	30	0.8	3	66	72	M6 70 mm
7	DELIXIN-LOK PCL 60.3 MM	60.3	122	118	94	30	0.8	3	93	99/103	M6 100 mm
7	DELIXIN-LOK PCL 63.5 MM	63.5	122	118	94	30	0.8	3	93	99/103	M6 100 mm
7	DELIXIN-LOK PCL 76.1 MM	76.1	122	118	94	30

Robust Material Choices for Diverse Applications

Select from Polypropylene, Polyamide, or Aluminum clamp bodies, matched with Stainless Steel 304 plates and fasteners, ensuring durability and excellent corrosion resistance. These materials cater to a variety of industrial needs, from standard hydraulic and pneumatic systems to environments demanding fire resistance or higher temperature tolerance.

Superior Noise and Vibration Reduction

The ribbed design of our tube clamps is engineered to absorb and minimize vibration and noise in piping systems. This not only enhances operational comfort but also protects the integrity of your installations over time, making them ideal for applications where noise control is essential.

Customizable and Modular Installation

Our clamps are straightforward to assemble, disassemble, and reconfigure thanks to their modular design. We offer customization to fit different tube sizes (from 6mm to 101.6mm), mounting requirements, and specialized applications, streamlining installation and future modifications.

FAQ's of SS 304 Tube Clamps:

Q: How are SS 304 Tube Clamps installed, and what mounting types are available?

A: SS 304 Tube Clamps can be quickly and securely installed using welded base or rail-mounted options. The modular construction ensures easy assembly and disassembly, accommodating both single and double clamp configurations as per your system's requirements.

Q: What pipe and tube sizes can these clamps support?

A: Our tube clamps are available for a diverse range of tube sizes, typically from 6mm to 101.6mm outside diameter. The inner diameter can be customized to fit the specific pipe size you require, ensuring a secure and precise fit for various applications.

Q: When should I choose Polypropylene, Polyamide, or Aluminum clamp bodies?

A: Polypropylene bodies are suitable for temperatures from -30C to +90C and general purposes. Polyamide offers higher temperature resistance up to +120C and is fire-resistant, while Aluminum versions excel in both high-temperature tolerance and fire resistance for specialized industrial settings.

Q: What benefits do these clamps offer for vibration and noise control?

A: The ribbed design of these clamps effectively reduces vibrations and minimizes operational noise in piping and hydraulic systems. This protective feature enhances both equipment longevity and workplace comfort, making them suitable for precision and sensitive installation environments.

Q: Where can these SS 304 Tube Clamps be used?

A: These clamps are suitable for hydraulic pipes, process and instrumentation tubes, and pneumatic lines across sectors like industrial manufacturing, oil and gas, chemical processing, and instrumentation where corrosion resistance and vibration control are priorities.

Q: How does the product ensure corrosion and fire resistance?

A: The use of Stainless Steel 304 for all metal parts provides excellent corrosion resistance, suitable for harsh environments. For fire resistance, Polyamide and Aluminum bodies are recommended, offering enhanced safety in high-risk or regulated environments.
